Integrated Pre-fabricated containeized substation for new energy

The inverter and booster integrated container substation is used to solve the problems of large construction volume and high power loss brought by the need to use two sets of equipment for DC inversion and AC boosting in photovoltaic power generation systems. The inverter and booster integrated container substation includes a low-voltage part, a high-voltage part and a voltage transformation part.

It is characterized in that the low-voltage part and the high-voltage part are arranged front and back, and the voltage transformation part is located on the left or right side of the low-voltage part and the high-voltage part; the low-voltage part collects the direct current generated by the photovoltaic power generation system and inverts it into alternating current; the voltage transformation part converts the low-voltage alternating current into high-voltage alternating current; the high-voltage part sets protection for the high-voltage alternating current and conducts metering. The inverter and booster integrated container substation is used to invert and boost the electrical energy generated by photovoltaic modules into stable utilisable electrical energy.
